UL/CSA预绝缘端子EN45545-2

UL/CSA预绝缘端子
符合UL/CSA认证，有圆形叉形和针形，线缆尺寸22 ～ 10AWG。

该系列绝缘端子的设计旨在满足对提高电气连接器安全性和可靠性的日益增长的需求。绝缘材质PVC，接线片由纯度超过99.9%的电解铜制成，由于采用退火处理和电镀锡，接线端子更容易压接，并且更能抵抗机械应力。铜管内部滚花设计通过增加整体牵引阻力来改善与电缆导体的接触。绝缘套管独特的漏斗形入口可确保导线完全插入端子筒中，从而形成安全可靠的电气和机械连接。工作温度范围为 –20 至 +80°C

RF-M2 RF-M3 RF-M3.5 RF-M3.5/1 RF-M4 RF-M4/3
RF-M5 RF-M6 RF-M6/1 RF-M7 RF-M8 RF-M10
RF-M12 BF-M2 BF-M3 BF-M3.5 BF-M3.5/1 BF-M4 4,9
BF-M5 BF-M6 BF-M6/1 BF-M6/2 BF-M7 BF-M8
BF-M10 BF-M12 GF-M3 GF-M3.5 GF-M4 GF-M5
GF-M6 GF-M6/1 GF-M7 GF-M8 GF-M8/1 GF-M10
GF-M10/1 GF-M12 GF-M14 GF-M16
RF-U3 RF-U3.5 RF-U3.5/1 RF-U3.5/2 RF-U4
RF-U4/1 RF-U4/2 RF-U5 RF-U5/1 RF-U6
RF-U6/1 RF-U8 RF-U10 RF-U12 BF-U3
BF-U3.5 BF-U3.5/1 BF-U4 BF-U4/1 BF-U4/2
BF-U5 BF-U5/2 BF-U6 BF-U6/1 BF-U8 BF-U10
BF-U12 GF-U3.5 GF-U4 GF-U5 GF-U6 GF-U8
GF-U10 GF-U10/1 GF-U12 GF-U14 GF-U16
RF-P8 RF-P10 RF-P12 BF-P8 BF-P10
BF-P12 GF-P10 GF-P12 GF-P14
RF-PP12 RF-PP12/1 RF-PP12/19 RF-PP12/23
RF-PP14 RF-PP16/23 BF-PP10 BF-PP12
BF-PP12/25 BF-PP12/29 BF-PP16/25
GF-PP12 GF-PP17
