POWER DISTRIBUTION BLOCKS

VERSIPOLE | 1000V
POWER DISTRIBUTION BLOCK
IP20 / UL / AL9CU

VERSIPOLE奔迪米色接线盒广泛用于从主线到支线的电路拼接或分接,它由标准模块和叠加模块两大类组成,标准模块可选一极,两极或三极的标准构造,而叠加模块可从一极叠加到所需要的无限极,最大化满足客户的各种现场需要。每个模块均可选择开放式或者防护式结构,防护式结构达到IEC60529 IP20防护等级,也可在开放式模块的基本上选购防护壳达到IP20等级;它们在尺寸上又分为大中小三个标准尺寸,小型最大电流176A,中型380A,大型760A;线路结构有一进四出,一进六出,一进一出,二进二出,二进六出,二进十二出等等。

  • 电压1000V,符合UL-1953
  • AL9CU材料适用于连接各类铜线和铝线
  • 适用于各类面板安装,大型和中型也可用于DIN德标导轨
  • 在正当的熔断下短路电流最大到100KA
  • 绝缘基础材料使用UL94V0玻璃增强尼龙66
  • 半透明PC材料防护外壳便于现场作业,并提供IP20防护等级
  • 防护外壳上盖为进出线路预留螺栓孔,方便固定线缆
  • 主线最多二线,支线最多可到十二线
  • 三种标准尺寸可适合各种空间应用
  • 美国设计美国制造

VERSI-POLE™ | 600V

PowerDistributionBlocks_image

VERSIPOLE 黑色接线盒

600V / UL / AL9CU

与米色接线盒相比,该款黑色接线盒也符合UL1953,使用AL9CU材料,但电压级别是600V,它也由标准模块和叠加模块两大类组成,标准模块为开放式,可以选购防护上盖起到保护作用,在尺寸上也分为大中小三个标准尺寸,小型最大电流175A,中型380A,大型可到840A;电路结构上,主线最多二线,支线最多十二线。美国制造,符合UL认证。

Features and Benefits

• “Add” a pole feature available.
Provides capability to create as many poles as required.
Up to 30 tap conductors accommodated, Ideal for current distribution to multiple locations.
• single or dual run connections.
Allows user to minimize the number of connectors needed to do the job.
• Suitable for use with aluminum or copper conductors.
Provides maximum versatility.
• 600 V, AL9CU rated.
Meets or exceeds industry standard requirements.
• Dead-front covers available.
Provides user protection one cover per pole.

SPEC-BLOK™

Unique, modular, made-to-order, power distribution assemblies accommodate any number of supply and load conductors in any number of poles. Capacity matches the conductors accommodated and SPEC-BLOK™ assures uniform loading. Adjacent poles are separated by easy-tohandle, wrap-around insulating covers which eliminate taping and reduce heat build-up by allowing air to flow freely around connectors. SPEC-BLOK™ is UL Listed for copper or aluminum conductors for 600 volts. (AL9CU) Assemblies are mounted on platforms suitable for easy installation in wireway or junction box.

• Accommodate unlimited conductors. Fits wide range of applications.Eliminates need for non-UL-listed improvisation.• Connector elements tin-plated.Provides high reliability, low-resistance connections.• User friendly, space-saving design.Easy to install. Saves labor.• 94-V0 rated insulation folds into place insulating the components.Saves time and material. Allows easy installation.• Connector caps removable for easy cable lay-in.Saves labor. Makes installation easier.Allows installation or straight-through conductors. Eases retrofit.• Belleville washers built-in on pressure screw assemblies, except in assembliesinstalled with a 5/32 Allen wrench. Provides high-integrity connections.• Conductors can be cut or fed straight through.Straight through installation ideal for riser applications.

U-BLOK™

UBLOKU-BLOK™ system is a modern, state-ofthe- art approach to multi-load power distribution applications. Among typical uses are multi-story or multi-unit buildings, HVAC, refrigeration, control panels, motor control, switch gear, elevator systems and materialshandling equipment. U-BLOK™ is UL Listed for Copper or Aluminum conductors and rated for 600-volt applications. U-BLOK™ can be mounted on bases for use in troughs or bolted directly to junction boxes. AL9CU rated.

Features and Benefits
• Connector top slides OFF/ON for quick cable lay-in.
◊ Labor savings. Easy access for installation, modifications or retrofit.
• Electro-tin plated connectors in each pole.
◊ Durability. High-conductivity and resistance to corrosion.
• Compact size.
◊ Requires less space than traditional connection methods.
• Trough installations can be mounted on raised platforms.
◊ Passage of cables under block means through-cables need not be terminated.
• Insulating covers and mounting blocks rated 94-V0.
◊ Saves costly taping, time and material. Conforms to or exceeds building codes.
• Connectors accommodate a wide range of wire sizes.
◊ Reduces parts inventory requirements.
• Feeder conductors can be cut or fed through on a continuous run.
◊ Ease of installation
