TWO HOLE SLOTTED HYLUG™ LONG BARREL WITH INSPECTION WINDOW

General Details

Compression Slotted Lugs connect copper or tinned copper conductors to bus bars, CPI Racks, Cabinets or Cable Runway. Slotted and 90° Slotted lugs have one round and one obround hole to match hole spacing on equipment mounting rails on CPI Racks and
Cabinets and on some bus bars.

UL Listed 90° C,600 Volts to 35 kV

YAZ8C2TC10SL
YAZ8C2TC1090SL #10 0.41 0.75 0.08 1.50 0.62 0.75 (2) Red 49 13/16
YAZ3C2TC38SL
YAZ3C2TC38SLBOX500 3/8 0.58 1.25 0.08 3.43 0.75 1 1 5/16
YAZ2C2TC38SL
YAZ2C2TC38SLBOX500
YAZV102TC14SL 14 – 10 AWG 1/4 Y8MRB-1
YAV102TC1090SL* #10 1 0.36 0.38 0.06 1.46 0.63 0.75 7/16
YAZV6C2TC38FXSLBOX500
YAZV6C2TC38FXSL 3/8 1 0.58 1.12 0.08 3.22 0.63 1
YAZV6C2TC14FXSLBOX500 1/4 1 0.58 1.12 0.08 3.22 0.63 1
YAZV6C2TC14FXSL 1/4 1 0.58 1.12 0.08 3.22 0.63 1
YAZV6C2TC10FX90SL #10 1 0.48 0.75 0.08 1.50 0.75 1
YAZV4C2TC14FXSL
YAZV4C2TC14FXSLBOX500 1/4 1 0.55 1.25 0.09 2.95 0.63 1
YAZV4C2TC38FXSL 3/8 1 0.55 1.25 0.09 2.95 0.63 1
YAZV4C2TC38FXSLBOX500 3/8 1 0.55 1.25 0.09 2.95 0.63 1
YAZV2C2TC14FXSL #2 AWG
YAZV2C2TC14FXSLBOX500 1/4 1 0.60 1.25 0.11 3.42 0.75 1
YAZV2C2TC38FXSL 3/8 1 0.60 1.25 0.11 3.42 0.75 1
YAZV2C2TC38FXSLBOX500 3/8 1 0.60 1.25 0.11 3.42 0.75 1
YAZV252TC14FXSL 1/0 AWG
YAZV252TC14FXSLBOX500 1/4 1 0.83 1.50 0.12 3.44 0.63 1
YAZV252TC38FXSL 3/8 2 0.83 1.50 0.12 3.44 0.63 1
YAZV252TC38FXSLBOX500 3/8 2 0.83 1.50 0.12 3.44 0.63 1
YAZV262TC14FXSL 2/0 AWG
YAZV262TC14FXSLBOX500 1/4 1 0.93 1.50 0.13 3.58 0.63 1
YAZV262TC38FXSL 3/8 1 0.93 1.50 0.13 3.58 0.63 1
YAZV262TC38FXSLBOX500 3/8 1 0.93 1.50 0.13 3.58 0.63 1
YAZV282TC14FXSL
YAZV282TC14FXSLBOX500 1/4 1 1.14 1.62 0.15 3.64 0.63 1
YAZV282TC38FXSL 3/8 1 1.14 1.62 0.15 3.64 0.63 1
YAZV282TC38FXSLBOX500

Features & Benefits

• Slotted stud provides built in flexibility for the terminal to conform to various space
requirements.
• Accommodates a wide range of conductor combinations (AWG, Compact, DLO, Flex and Metric).
