RH50六角远传分体式压接液压钳头CE认证

RH50液压头适用于在最大300mm2导体上安装压接电气连接器。它采用标准模具组，兼容其他工具和50KN的钳头。 可打开钳头配备带有自动锁定功能的快拆转接头。可与最大工作压力为700 BAR的液压泵结合使用。

The RH50 hydraulic head is suitable for installing crimping electrical connectors on conductors up to 300 mm2. It adopts the standard die set compatible with other tools and 50 kN heads. The head can be opened and is complete with a male quick-release coupling with automatic locking. For its operation it is necessary to combine it with a hydraulic pump with a maximum working pressure of 700 bar.

压接压力：50KN
工具尺寸：20 x 7.5 cm 重量1.6kg
压接能力：铜鼻子4~300mm2| 绝缘端子10~120mm2 | C形线夹4~70mm2
工作温度范围 -15 – 50°C
