◎ Rated Current and Voltage :3A, 50V AC(r.m.s)
◎ Dielectric Withstanding Voltage : 1000V AC for one minute
◎ Contact Resistance : <20mΩ
◎ Insulation Resistance : >1000MΩ
◎ Operating Temperature : -25℃~85℃
◎ RoHS Compliant
CIRCUITS | 03, 04, 05
CIRCUTS |
||
---|---|---|---|
Plating Code | 1= Matte Tin Plated over Nickel 4= Gold Flash Plated over 50μ” Nickel |
